Siglent SPD3303X-E ::: Linear DC 3CH programmable power supply

Product Overview

Siglent’s SPD3000X Series Programmable Linear DC Power Supply has a 4.3 inch TFT-LCD display, supports Remote Programming and has a Real Time Wave Display. The ‘3000X family has three isolated outputs; two adjustable channels and one selectable channel from 2.5 V, 3.3 V, and 5 V. It also has output short and overload protection and can be used in production and development.

Key Features

• 100/120/220/230 V compatible design to meet the needs of different power grids
• Intelligent temperature-controlled fan effectively reduces fan noise
• Clear graphical interface, with waveform display function
• Five internal groups of system parameter save/recall, supports data storage space expansion
• Free PC software: Easypower. Also supports remote programming and includes a LabView driver

Siglent’s SPD3303X-E Series Programmable Linear DC Power Supply has a 4.3 inch TFT-LCD display, supports Remote Programming and has a Real Time Wave Display.

Series Output Mode

Series/parallel/independent mode functions

Series and parallel functions allows for combining two channels into one output with more power output capability, extending the application range. Each of 3 channels power can be turned on or off independently and also can be turned all on or all off.

Parallel Output Mode

Series/parallel/independent mode functions

Series and parallel functions allows for combining two channels into one output with more power output capability, extending the application range. Each of 3 channels power can be turned on or off independently and also can be turned all on or all off.

Panel Timing Output

Panel displays the timing output

Through front panel operation, five groups of timing settings and output control can be displayed, which provides users with simple power programming functionality. Also, by connection to Siglent’s EasyPower PC software, a full range of communication and control features can be used.
